TP4056 Type-C Charging Module

TP4056 Type-C Lithium Battery Charger Protection Module. The reliable $1\text{A}$ CC/CV linear charger now featuring a modern USB Type-C input for single $3.7\text{V}$ Li-ion/Li-Po cells. Includes the necessary DW01 protection circuit to prevent over-discharge and short circuits. This compact module is perfect for upgrading DIY power banks and any portable project using the latest USB standard.

Product Details

The TP4056 Type-C Charging Module offers all the reliability and simplicity of the original TP4056 chip while providing the convenience of the reversible USB Type-C input. It is the perfect, low-cost solution for safe, standard-speed charging of single Lithium battery cells.

• Modern Input: Features a highly durable and reversible USB Type-C port for easy power connection using standard $5\text{V}$ Type-C cables and power adapters.

• Standard Charging Rate: Charges single Lithium-Ion cells to $4.2\text{V}$ with a dependable current of $1\text{A}$ (adjustable by changing a resistor).

• Battery Protection Included: Most Type-C versions integrate the DW01A battery protection circuitry, providing crucial safeguards against over-discharge, over-current, and short circuits.

• Visual Status: Equipped with clear LED indicators (Red = Charging, Blue/Green = Full Charge) for straightforward monitoring of the charging status.

• Compatibility: Ideal for $3.7\text{V}$ (nominal) Lithium Polymer and Lithium-Ion batteries used in small gadgets and wearable electronics.
